| Video/Audio Input |
| Video Compression: |
H.264 |
| Analog Video Input: |
16-ch |
| PAL/NTSC Adaptive: |
Support |
| Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: |
G.711u |
| Audio Input: |
4-ch |
| Audio Input Interface: |
RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: |
1-ch RCA(2.0Vp-p, 1kΩ) |
|
| Video/Audio Output |
| VGA Output: |
1-ch, resolution:
1920×1080P/60Hz,1280×1024/60Hz,1280×720/60Hz, 1024×768/60Hz |
| CVBS Output: |
2-ch (1 Main Video Out+1 Spot Video Out),
BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704×576, NTSC: 704×480 |
| HDMI Output: |
1-ch, resolution:
1920×1080P /60 Hz, 1280×1024 /60 Hz,1280×720 /60 Hz, 1024×768 /60 Hz. |
| Recording resolution: |
4CIF/2CIF/CIF/QCIF |
| Frame Rate: |
25 fps (P) / 30 fps (N) |
| Video Bit Rate: |
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps) |
| Stream Type: |
Channel 1-4: Video, Video & Audio;
Other channels: Video |
| Audio Output: |
2-ch RCA(Linear electrical level, 600Ω) |
| Audio Bit Rate: |
64kbps |
| Dual Stream: |
Support |
| Synchronous Playback: |
16-ch |
|
| Hard Disk Driver |
| Interface Type: |
4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs |
| Capacity: |
Up to 4TB capacity for each disk |
| e-SATA Interface: |
1 eSATA interface |
|
| External Interface |
| Network Interface: |
1 RJ45 10M/100M/1000M adaptive Ethernet Interface |
| USB Interface: |
3 USB2.0 interfaces |
| Serial Interface: |
1RS-485 interface, 1 RS-232 interface, 1 RS-485 keyboard interface |
| Alarm Input: |
16-ch |
| Alarm Output: |
4-ch |
|
| General |
| Power Supply: |
100 ~ 240 VAC, 5A, 50~60Hz |
| Consumption: |
≤ 35W (without hard disk
or DVD-R/W) |
| Working Temperature: |
-10 °C ~ + 55 °C |
| Working Humidity: |
10% ~ 90% |
| Chassis: |
19-inch rack-mounted 1.5 U chassis |
| Dimensions: |
445(W) × 390(D) × 70(H) mm |
| Weight: |
≤ 5kg (without hard disk or DVD-R/W) |
|
