| Video/Audio Input |
| Video Compression: |
H.264 |
| Analog Video Input: |
16-ch |
| PAL/NTSC Adaptive: |
Support |
| Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: |
G.711 |
| Audio Input: |
16-ch |
| Audio Input Interface: |
BNC (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: |
1-ch BNC(2.0Vp-p, 1kΩ) |
|
| Video/Audio Output |
| VGA Output: |
1-ch, resolution: 1024×768/60Hz |
| CVBS Output: |
2-ch, BNC (1.0 Vp-p, 75 Ω);
Resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Recording resolution: |
4CIF/2CIF/CIF/QCIF |
| Frame Rate: |
4CIF / 2CIF: 6 fps;
CIF / QCIF:
25 fps (P) / 30 fps (N) |
| Video Bit Rate: |
32Kbps~2048Kbps, or user-defined |
| Stream Type: |
Video/Video&Audio |
| Audio Output: |
1-ch BNC(Linear electrical level, 600Ω) |
| Audio Bit Rate: |
64kbps |
| Dual Stream: |
Support |
| Synchronous Playback: |
16-ch |
|
| Hard Disk Driver |
| Interface Type: |
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs |
| Capacity: |
Up to 2TB capacity for each disk |
| e-SATA Interface: |
1 eSATA interface |
|
| External Interface |
| Network Interface: |
1 RJ45 10M/100M adaptive Ethernet Interface |
| USB Interface: |
3 USB2.0 interfaces |
| Serial Interface: |
1RS-485 interface, 1 RS-232 interface, 1 RS-485 keyboard interface |
| Alarm Input: |
16-ch |
| Alarm Output: |
4-ch |
|
| General |
| Power Supply: |
100 – 240 V AC, 6.3 A, 50 – 60 Hz |
| Consumption: |
≤ 50 W (without hard disk or DVD-R/W) |
| Working Temperature: |
-10 °C – +55 °C (14 °F – 131 °F) |
| Working Humidity: |
10% – 90% |
| Chassis: |
19-inch rack mounted 2U chassis |
| Dimensions: |
95 (H) × 450 (W) × 450 mm (D) (3.74″ (H) × 17.72″ (W) × 17.72″ (D)) |
| Weight: |
≤ 8000 g (17.64 lbs)
(without hard disk) |
|
